Meat Vegetable Transport Roof Type Truck Freezer Unit , Reefer Unit For Cargo Van
Product Details:
Place of Origin: | CHINA |
Brand Name: | SNOWFALL |
Certification: | CE, ISO |
Model Number: | SF-T200 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1set |
---|---|
Packaging Details: | Carton/ Woodcase |
Delivery Time: | 10 days |
Supply Ability: | 50sets/Month |
Detail Information |
|||
Product Type: | Transport Refrigeration Units | Condenser Type: | Microchannel |
---|---|---|---|
Cooling Capacity: | 2100Kcal/hr | Dimensions: | 920x660x220mm, 640x790x180mm |
Warranty: | 1years | Weight: | 38kg |
Temperature Range: | -20°C To 15°C | Voltage: | DC 12V / DC 24V |
Compressor Type: | Scroll | Refrigerant Type: | R-404A/ R-134A |
Fuel Type: | Directy Drive By Truck Engine | Evaporator Type: | Inner Screw Tube And Aluminum Fin |
Highlight: | Roof Type Truck Freezer Unit,Transport Reefer Unit For Cargo Van,Vegetable Transport Truck Freezer Unit |
Product Description
Meat Vegetable Transport Roof Type Truck Freezer Unit
Reefer Unit For Cargo Van
Key Features
- Microchannel condenser for efficient cooling
- Scroll compressor technology for reliable performance
- Wide temperature range: -20°C to 15°C
- Direct drive by truck engine
- Automatically hot air defrost system
- Compact and lightweight design
Technical Specifications
Attribute | Value |
---|---|
Product Type | Transport Refrigeration Units |
Model | SF-T200 |
Cooling Capacity | 2100Kcal/hr (2100W at 0°C) |
Temperature Range | +20°C to -18°C |
Compressor Type | Scroll (Model SD5H11/5H14) |
Refrigerant Type | R-404A/ R-134A |
Voltage | DC 12V / DC 24V |
Power Consumption | ≤ 22A(12V) / ≤ 11A(24V) |
Dimensions | Evaporator: 790×590×170mm Condenser: 920×660×210mm |
Weight | Evaporator: 18.62kg Condenser: 23kg |
Warranty | 1 year |
Component Details
Condenser Type:
Microchannel (P.F.) with axial fan (1000m³/h)
Evaporator Type:
Inner screw tube and aluminum fin with axial fan (800m³/h)
Defrost System:
Automatically hot air defrost
Structure:
Split direct drive unit
