Product Details:

Get Best Price Contact Now

Detail Information

Colour: White Fan Material: Aluminium Alloy
Condensor Design: Latest Exclusively For Refrigeration Unit Sealing Technology: Patented O Sealing Technology
Durability Range: The Highest Level Maintenance: Lower The Cost Of Maintance
Transport Package: Carton Trademark: SNOWFALL
Origin: Guangzhou, China HS Code: 8418692090
Supply Ability: 5000 Sets/ Year Type: Cooling System
Application Fields: Refrigerated Trucks Condition: New
Service: OEM Installation: Front, Roof, Under Mounting Type
Electric: Optional Electric Standby System Customization: Available | Customized Request
Highlight:

Frozen Food Transport Cooling Units

,

Refrigerated Chiller Unit Front Installation

Product Description

Frozen Food Transport Cooling Units Refrigerated Chiller Unit Front Installation
Product Attributes
Colour: White
Fan Material: Aluminium Alloy
Condensor Design: Latest Exclusively for Refrigeration Unit
Sealing Technology: Patented O Sealing Technology
Durability Range: The Highest Level
Maintenance: Lower The Cost of Maintenance
Transport Package: Carton
Trademark: SNOWFALL
Origin: Guangzhou, China
HS Code: 8418692090
Supply Ability: 5000 Sets/Year
Type: Cooling System
Application Fields: Refrigerated Trucks
Condition: New
Service: OEM
Installation: Front, Roof, Under Mounting Type
Electric: Optional Electric Standby System
Customization: Available
Product Description
Truck refrigeration units SF-318 featuring latest design condenser, patented O sealing technology, and SD5H14 compressor model using R-134a refrigerant.
Main Specifications
  • Applicable Temperature: 20°C ~ -5°C
  • Cooling Capacity: 1800Kcal/2093W/714BTU at 0°C
  • Compressor Model: SD5H14 with 138 cc/r displacement
  • Condenser Type: P.F. with axial fan (1 fan × 800m³/h)
  • Evaporator Type: Inner screw tube and aluminum fin with axial fan (1 fan × 1000m³/h)
  • Power Consumption: ≤22A (DC12V) or ≤11A (DC24V)
  • Refrigerant: R-134a
  • Structure: Split direct drive unit
Dimensions & Weight
Component Dimensions (mm) Net Weight
Condenser 800×480×180 (31"×19"×7") 17.88 kg
Evaporator 790×590×170 (31"×23"×6.7") 18.34 kg
SF-T318 Condenser 870×700×150 21.33 kg
Optional Features
  • Electrical Standby System: AC 220V/380V/415V
  • Customization available upon request

Our refrigeration units have been exported worldwide to North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, and Western Europe, earning excellent reputation in global markets.
