MOQ: | 2 set |
Standard Packaging: | Woodcase |
Delivery Period: | 5 days |
Supply Capacity: | 100 sets/Month |
Introduce:
It is suitable for refrigerating vehicles of light trucks and above, with remarkable refrigeration effect under the volume of 14-23m.
It is the first choice for transporting refrigerated frozen food, dairy products, fruits, ice cream, fresh agricultural products and industrial electronic products, with very stable and reliable refrigeration performance.
The engine-driven transport refrigerating unit SF-700 sub-unit is a reliable refrigerating unit for light truck thermal insulation vehicles with a size of 14~ 23m.
Feature:
The whole transport refrigerating unit is light and compact, the condenser is in front, the 12-inch large aluminum alloy vane motor imported from Taiwan, the evaporator can be installed as required.
3. This series of models fully covers the freezing capacity ranging from 14 m to 56m and accurately matches its freezing volume from per square meter.
4. Each SNOWFALL will be featured with low cost, low maintenance, low noise, energy saving and environmental protection.
Model |
SF - 700 |
|||
Applicable Temperature (℃) |
15 ~ -20 |
|||
Cooling Capacity |
Environmental Temperature |
35°C |
||
0°C |
5800Kcal |
|||
-18°C |
3250Kcal |
|||
Compressor |
Model |
QP16/QP21 |
||
Displacement(cc/r) |
215cc |
|||
Condenser |
Type |
P.F. |
||
Fan Type |
Axial fan |
|||
Number of Fan |
3Fans x 1000m3/h |
|||
Voltage |
DC 12V/DC24V |
|||
Evaporator |
Type |
Inner screw tube and aluminium fin |
||
Fan Type |
Axial fan |
|||
Number of Fan |
3Fans x1000m3/h |
|||
Voltage |
DC 12V/DC24V |
|||
Power Consumption |
≤ 37.5A (DC12V) |
|||
Refrigerant |
R-134a/R-404a |
|||
Defrost Type |
Automatically hot air defrost |
|||
Structure |
Split direct drive unit |
|||
Dimensions (mm) /Net weight(kg) |
SF-700 Evaporator |
L570x W1240x H240 |
31.4 kg |
|
SF-700 Condenser |
L570 x W1260 x H435 |
54.3kg |
||
Electric Standby system(optional part) |
AC 220V /AC 380V |
