OEM Electric Transport Refrigeration Unit For Food Van / Truck / Motorbike
Product Details:
Get Best Price Contact Now|
Detail Information |
|||
| Model NO.: | SF-200 | Sealing Technology: | Patented O Sealing Technology |
|---|---|---|---|
| Design Base Environment: | 45 Degree C | Durability Range: | The Highest Level |
| Maintenance: | Lower The Cost Of Maintance | Transport Package: | Carton Filled With Paper Honeycomb |
| Trademark: | SNOWFALL | Origin: | Guangzhou, China |
| HS Code: | 8418692090 | Supply Ability: | 300 Sets Per Month |
| Service: | OEM | Installation: | Front, Roof, Under Mounting Type |
| Electric: | Optional Electric Standby System | Colour: | White |
| Fan Material: | Aluminium Alloy | Condensor Design: | Latest Exclusively For Refrigeration Unit |
| Customization: | Available | Customized Request | ||
| Highlight: | OEM Electric Transport Refrigeration Unit,Food Van Transport Refrigeration Unit |
||
Product Description
OEM Electric Transport Refrigeration Unit For Food Van / Truck / Motorbike
Product Specifications
Model NO.
SF-200
Sealing Technology
Patented O Sealing Technology
Design Base Environment
45 Degree C
Durability Range
The Highest Level
Maintenance
Lower The Cost of Maintenance
Transport Package
Carton Filled with Paper Honeycomb
Trademark
SNOWFALL
Origin
Guangzhou, China
HS Code
8418692090
Supply Ability
300 Sets Per Month
Service
OEM
Installation
Front, Roof, Under Mounting Type
Electric
Optional Electric Standby System
Colour
White
Fan Material
Aluminium Alloy
Condenser Design
Latest Exclusively for Refrigeration Unit
Customization
Available
Product Gallery
Product Description
The SNOWFALL SF-200 is an engine-driven transport refrigeration unit designed for micro and light truck applications. Ideal for transporting refrigerated food, dairy products, vegetables, and fruits, this unit offers reliable temperature control for vehicles with 7-14m³ capacity.
Key Features
- Optional DC 12V or 24V power configuration
- Lightweight and compact design with front-mounted condenser
- Precisely matches refrigerated volume requirements from 7m³ to 14m³
- Low maintenance, low noise operation with energy-efficient performance
- Environmentally friendly R134a refrigerant
- Automated hot air defrost system
- Split direct drive unit structure
Technical Specifications
| Model | SF-200 |
|---|---|
| Applicable Temperature | 15°C to -18°C |
| Cooling Capacity (35°C environment) | 0°C: 2100 Kcal -18°C: 1210 Kcal |
| Compressor | Model: SD5H11/5H14 Displacement: 110cc/138cc |
| Condenser | Type: P.F. Fan: 1 Axial fan (1000m³/h) |
| Evaporator | Type: Inner screw tube and aluminium fin Fan: 1 Axial fan (1000m³/h) |
| Power Consumption | ≤ 33A (DC12V) ≤ 16.5A (DC24V) |
| Refrigerant | R-134a/R-404a |
| Dimensions & Weight |
Evaporator: 610×790×180mm (16.5kg) Condenser: 520×840×315mm (18.2kg) T200 Condenser: 610×790×180mm (21.33kg) T200 Condenser: 920×660×200mm (23.33kg) |
SNOWFALL refrigeration units are known for their high quality, competitive pricing, and reliability. Our products have been exported worldwide to North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, the Middle East, Eastern Asia, and Western Europe, earning an excellent reputation in the industry.
