Front Installation Chiller Food Truck Refrigerator Unit Cooling System Freezer Equipment
Product Details:
Get Best Price Contact Now|
Detail Information |
|||
| Colour: | White | Fan Material: | Aluminium Alloy |
|---|---|---|---|
| Condensor Design: | Latest Exclusively For Refrigeration Unit | Sealing Technology: | Patented O Sealing Technology |
| Durability Range: | The Highest Level | Maintenance: | Lower The Cost Of Maintance |
| Transport Package: | Carton | Trademark: | SNOWFALL |
| Origin: | Guangzhou, China | HS Code: | 8418692090 |
| Supply Ability: | 5000 Sets/ Year | Type: | Cooling System |
| Application Fields: | Refrigerated Trucks | Condition: | New |
| Service: | OEM | Installation: | Front, Roof, Under Mounting Type |
| Electric: | Optional Electric Standby System | Customization: | Available | Customized Request |
| Highlight: | Front Installation Truck Refrigerator Unit,Chiller Food Truck Freezer Equipment |
||
Product Description
Front Installation Chiller Food Truck Refrigerator Unit Cooling System Freezer Equipment
Product Attributes
| Colour | White |
| Fan Material | Aluminium Alloy |
| Condensor Design | Latest Exclusively for Refrigeration Unit |
| Sealing Technology | Patented O Sealing Technology |
| Durability Range | The Highest Level |
| Maintenance | Lower The Cost of Maintenance |
| Transport Package | Carton |
| Trademark | SNOWFALL |
| Origin | Guangzhou, China |
| HS Code | 8418692090 |
| Supply Ability | 5000 Sets/Year |
| Type | Cooling System |
| Application Fields | Refrigerated Trucks |
| Condition | New |
| Service | OEM |
| Installation | Front, Roof, Under Mounting Type |
| Electric | Optional Electric Standby System |
| Customization | Available |
Product Description
Truck Refrigeration Units SF-318
- Latest design condenser
- O good sealing
- Compressor Model: SD5H14
- R-134a refrigerant
Main Specifications
Applicable Temperature: 20°C ~ -5°C
Cooling Capacity: 0°C 1800Kcal/2093W/714BTU
Compressor
- Model: SD5H14
- Displacement(cc/r): 138
Condenser
- Type: P.F.
- Fan Type: Axial fan
- Number of fan: 1fan*800m3/h
- Voltage: DC12V/DC24V
Evaporator
- Type: Inner screw tube and aluminum fin
- Fan type: Axial fan
- Number of fan: 1fan*1000m3/h
- Voltage: DC12V/DC24V
Power consumption: Between 22A(DC12V) and 11A(DC24V)
Refrigerant: R-134a
Structure: Split direct drive unit
Dimensions/Net Weight:
- Condenser: 800*480*180mm (31"*19"*7")/17.88kgs
- Evaporator: 790*590*170mm (31"*23"*6.7")/18.34kgs
Our products have been exported to many countries for years and enjoyed great reputation. Our overseas markets include North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, and Western Europe.
Product Images
Technical Specifications
| Specification | Details |
|---|---|
| Unit Model | SF-318 |
| Applicable Temperature | 20°C ~ -5°C |
| Cooling Capacity | Environmental Temperature: 35°C 0°C: 1800Kcal/2093W/7142BTU |
| Compressor | Model: SD5S14 Displacement(cc/r): 138 |
| Condenser | Type: P.F. Fan Type: Axial Fan Number of Fan: 1 Fans * 800m³/h Voltage: DC 12V / DC 24V |
| Evaporator | Type: Inner screw tube and aluminium fin Fan Type: Axial Fan Number of Fan: 1 Fans * 1000m³/h Voltage: DC 12V / DC 24V |
| Power Consumption | ≤22A(DC 12V) ≤11A(DC 24V) |
| Refrigerant | R-134a |
| Structure | Split direct drive unit |
| Electrical Standby System (optional) | AC 220V / AC 380V/ 415V |
| Dimensions & Net Weight |
SF-318 Evaporator: 790*590*170mm | 18.34kg SF-318 Condenser: 800*480*180mm | 17.88kg SF-T318 Condenser: 870*700*150mm | 21.33kg |
