Truck Refrigerator for Refrigerated Truck SF-328 Lowering Your Maintenance Expenses
Product Details:
Get Best Price Contact Now|
Detail Information |
|||
| Model NO.: | SF-328 | Sealing Technology: | Patented O Sealing Technology |
|---|---|---|---|
| Design Base Environment: | 45 Degree C | Durability Range: | The Highest Level |
| Maintenance: | Lower The Cost Of Maintance | Transport Package: | Carton Filled With Paper Honeycomb |
| Trademark: | SNOWFALL | Origin: | Guangzhou, China |
| HS Code: | 8418692090 | Supply Ability: | 300 Sets Per Month |
| Service: | OEM | Installation: | Front, Roof, Under Mounting Type |
| Electric: | Optional Electric Standby System | Colour: | White |
| Fan Material: | Aluminium Alloy | Condensor Design: | Lastest Exclusively For Refrigeration Unit |
| Customization: | Available | Customized Request | ||
| Highlight: | customized truck refrigeration unit,customized transport refrigeration units,under mounting truck refrigeration unit |
||
Product Description
Truck Refrigerator for Refrigerated Truck SF-328 - Lower Maintenance Costs
Product Specifications
| Attribute | Value |
|---|---|
| Model NO. | SF-328 |
| Sealing Technology | Patented O Sealing Technology |
| Design Base Environment | 45°C |
| Durability | Highest Level |
| Maintenance | Lower Maintenance Costs |
| Transport Package | Carton Filled with Paper Honeycomb |
| Trademark | SNOWFALL |
| Origin | Guangzhou, China |
| HS Code | 8418692090 |
| Supply Ability | 300 Sets Per Month |
| Service | OEM |
| Installation | Front, Roof, Under Mounting Type |
| Electric | Optional Electric Standby System |
| Colour | White |
| Fan Material | Aluminium Alloy |
| Condenser Design | Latest Exclusive for Refrigeration Unit |
| Customization | Available |
Technical Specifications
- Model: SF-T328 Truck Refrigeration Unit
- Key Function: Maintains optimal freshness and cooling for transported goods
- Compressor: SD5H14 (Made in Singapore)
- Defrost System: Automatic hot air defrost
Performance Details
Applicable Temperature Range: 15°C to -20°C
Cooling Capacity (at 0°C): 2800Kcal/3256W/11109BTU
Cooling Capacity (at -18°C): 1750Kcal/2035W/6943BTU
Component Specifications
Compressor:
Type: Swash plate
Displacement: 138 cc/r
Lubrication: POE
Condenser:
Type: P.F
Fan: 2 axial fans (1000m³/H each)
Voltage: DC12V/DC24V
Evaporator:
Type: Inner screw tube with aluminum fin
Fan: 2 axial fans (1000m³/H each)
Voltage: DC12V/DC24V
Power Consumption: 33A (DC12V) to 16.5A (DC24V)
Refrigerant: R-134a or R404a
Throttle Type: External equalizer expansion valve
Structure: Split direct drive unit
Dimensions & Weight
Evaporator: 1270×580×170mm (50"×23"×7") - 31.63kg
Condenser: 1000×900×170mm (39"×35"×7") - 33.87kg
Quality Assurance
Our truck refrigeration units are manufactured to the highest quality standards, offering reliable performance at competitive prices. SNOWFALL products have been exported worldwide and enjoy excellent reputation in markets including:
- North & South America
- Europe (Eastern & Western)
- Asia (Eastern & Southeast)
- Africa, Oceania, and Middle East
Want to Know more details about this product
