150-250hp Plastic Honeycomb Cargo Truck Box Dry Freight Body Wind Resistant
Product Details:
| Place of Origin: | China |
| Brand Name: | SNOWFALL |
| Certification: | ISO , SGS, CE |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | flat pack |
| Delivery Time: | 10 days |
| Supply Ability: | 200 sets per month |
|
Detail Information |
|||
| Model NO.: | Dry Truck Body | Seats: | ≤5 |
|---|---|---|---|
| Horsepower: | 150-250hp | Engine Capacity: | 4-6L |
| Heat Preservation Type: | Foam Material | Tire Certification: | ISO |
| Tire Design: | Radial | Condition: | New |
| Colour: | White Or Other Colour | Transport Package: | CKD |
| Specification: | As Per Request | Trademark: | SNOWFALL |
| Origin: | China | HS Code: | 8707901000 |
| Supply Ability: | 120 Set | Transmission Type: | Cargo Van |
| Emission Standard: | Euro 5 | Power: | Diesel |
| Load Capacity: | 1-10t | Drive Wheel: | 4×2 |
| Shape: | Single Bridge | Customization: | Available | Customized Request |
| Highlight: | Plastic Honeycomb Cargo Truck Box,Wind Resistant Plastic Honeycomb,Dry Freight Body Wind Resistant |
||
Product Description
150-250hp Plastic Honeycomb Cargo Truck Box Dry Freight Body Wind Resistant
Model NO.
Dry Truck Body
Seats
≤5
Horsepower
150-250hp
Engine Capacity
4-6L
Heat Preservation Type
Foam Material
Tire Certification
ISO
Tire Design
Radial
Condition
New
Colour
White or Other Colour
Transport Package
CKD
Specification
as per request
Trademark
SNOWFALL
Origin
China
HS Code
8707901000
Supply Ability
120 Set
Transmission Type
Cargo Van
Emission Standard
Euro 5
Power
Diesel
Load Capacity
1-10t
Drive Wheel
4×2
Shape
Single Bridge
Customization
Available
Material Composition
FRP with PP Honeycomb panel for roof, side wall, front, rear door. The floor features steel checkered plate. Includes double rear door with stainless steel door frame and locking. Available in CKD or assembled type.
Specifications
- Glass reinforced fiber plastic + PP honeycomb cellcore + glass reinforced fiber plastic
- Thickness of GFRP: 1mm to 2.5mm
- Surface options: Anti-slip pattern and diamond pattern
Key Features
- Light-weight construction saves energy and reduces costs
- High strength design
- Water-proof and flame retardant
- Excellent weather resistance against moisture and aging
- Effective shock absorption
- Easy to fabricate
- Sound insulation properties
- Colorful and decorative options
- Environmentally friendly materials
- Low electrical & thermal conductivity
Product Images
Standard Dimensions
| Dimension | 3160mm | 4380mm | 6250mm |
|---|---|---|---|
| Length (L) | 3160mm | 4380mm | 6250mm |
| Width (W) | 1740mm | 2000mm | 2450mm |
| Height (H) | 1650mm | 1920mm | 2300mm |
Panel Specifications
- Panel Type: FRP + Honeycomb + FRP
- Roof Panel: 1.5mm + 18mm + 1.5mm
- Front Panel: 1.5mm + 18mm + 1.5mm
- Wall Panel: 1.5mm + 18mm +1.5mm
- Floor Panel: 3mm Steel Checked Plate
- Rear Door: 1 pair of 20mm thick FRP plywood swing doors
Customization Available: Sizes from 2m to 9m can be customized to your specific requirements. Please provide details for a custom quote.
