FRP Refrigerated Truck Box 150 Sets Month High Strength
Product Details:
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 2500 |
|
Detail Information |
|||
| Outer Material: | FRP | Inner Material: | FRP |
|---|---|---|---|
| Insulation Material: | Extruded Polystyrene Foam | Panel Construction: | Sandwich Type |
| Heat Conductivity: | 0.20W/M².K (FRP), 0.018-0.028W/M².K (polyurethane Foam) | Heat Transference: | Below 0.3W/M².K |
| Weight Reduction: | 30-40% Lighter Than Traditional | Fire Retardant: | B1 Level |
| Service Life: | 4-6 Times Longer Than Traditional | Surface Strength: | High Tensile, Bending, Impact |
| Chemical Resistance: | Acid, Alkali, Rainwater | Water Impermeability: | Excellent |
| Floor Material: | Figured Aluminum Panel | Production Capacity: | 150 Sets/month |
| Assembly Method: | Adhesive And Rivet | ||
| Highlight: | FRP refrigerated truck box,high strength refrigerated truck box,150 sets refrigerated truck box |
||
Product Description
Fiberglass Skin Truck Body Insulated Box
High-performance refrigerator truck body designed for optimal thermal insulation and durability.
Material & Performance
- New type FRP (Fiberglass Reinforced Plastic) used for outer and inner skin
- Sandwich panel construction with extruded polystyrene foam core for superior thermal insulation
- Panels fixed to steel frame with high-strength adhesive and rivets for maximum durability
Construction
- Fully enclosed structure with all panels adhered using high-strength structural adhesive
- Designed for reliable conjunction, excellent sealing, and optimal insulation properties
- Modular design allows for easy and fast assembly
Specifications
- High-precision door panels with imported sealing rubber for superior airtight and thermal insulation
- Interior and exterior finished with aluminum alloy profiles or stainless steel components
- Protection guardrails installed on sides and rear, with integrated lighting system
- Reinforced floor design with high-quality figured aluminum panels for exceptional load capacity and wear resistance
- Customizable design options available for materials, structure, and refrigeration systems
- Optional interior compartments available for different temperature zone requirements
Key Properties
| Property | Details |
|---|---|
| Weight | 30-40% lighter than traditional domestic products |
| Thermal Insulation | Overall heat transfer coefficient (K-value) below 0.3W/M².K |
| Surface Durability | High tensile strength, chemical resistance, UV protection, and easy maintenance |
| Water Resistance | Excellent impermeability on both FRP surfaces |
| Fire Safety | Conforms to national standard B1 level |
| Service Life | 4-6 times longer than traditional products |
| Maintenance | Repairs leave no visible traces on panels |
| Environmental | No volatile or corrosive substances; fluorine-free foam core |
| Refrigeration | Compatible with USA, German, or Chinese refrigeration systems |
Our products have been exported internationally for years and enjoy excellent market reputation.
