Custom Refrigerated Truck Box 8ft to 32ft High Strength FRP
Product Details:
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 |
|---|---|
| Price: | 4800 |
|
Detail Information |
|||
| Outer Material: | FRP | Inner Material: | FRP |
|---|---|---|---|
| Insulation Material: | Extruded Polystyrene Foam | Heat Conductivity: | 0.20W/M².K (FRP), 0.018-0.028W/M².K (polyurethane Foam) |
| Overall Heat Transfer: | Below 0.3W/M².K | Weight Reduction: | 30-40% Lighter Than Traditional |
| Fire Retardant Level: | B1 | Service Life: | 4-6 Times Longer Than Traditional |
| Floor Material: | Figured Aluminum Panel | Door Sealing: | Imported Rubber |
| Edge Material: | Aluminum Alloy/stainless Steel | Hinge Material: | Stainless Steel/galvanized |
| Length Options: | 8ft To 32ft | Production Capacity: | 150 Sets/month |
| Compartment Customization: | Multi-temperature Zones | ||
| Highlight: | custom refrigerated truck box,FRP refrigerated truck box,high strength refrigerated truck box |
||
Product Description
Transport Refrigeration Truck Box Freezer Body Chiller Box
High-performance refrigerated truck body designed for optimal thermal insulation and durability in transport refrigeration applications.
Material & Performance
- New type FRP (Fiberglass Reinforced Plastic) used for outer and inner skin
- Sandwich panel construction with extruded polystyrene foam core for superior thermal insulation
- Panels fixed to steel frame with high-strength adhesive and rivets for structural integrity
Construction
- Fully enclosed structure with high-strength structural adhesive for reliable sealing and insulation
- Designed for easy and fast assembly
Specifications
High-accuracy door panels with imported sealing rubber for excellent airtight and thermal insulation
Interior and exterior finished with aluminum alloy profiles or stainless steel components
Protection guardrails on sides and rear with integrated lighting
Reinforced floor design with figured aluminum panels for strength and wear resistance
Customizable design options for materials, structure, and refrigeration units
Available with interior compartments for different temperature zones
Key Properties
- Lightweight: 30-40% lighter than traditional products
- Thermal Insulation: Overall heat transfer coefficient below 0.3W/m²·K
- Durable Surface: High tensile strength, chemical resistance, and UV protection
- Waterproof: Excellent water impermeability on both sides
- Fire Retardant: Meets national standard B1 level
- Long Service Life: 4-6 times longer than traditional products
- Easy Maintenance: Repairs leave no visible traces
- Eco-Friendly: No volatile substances, fluorine-free insulation
- Refrigeration Options: Available with USA, German, or Chinese refrigeration units
Our products have been exported worldwide and are well-established in markets including North America, South America, Europe, Asia, Africa, and Oceania.
