SNOWFALL Refrigerated Truck Box with High Strength FRP Panels
Product Details:
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 2000 |
|
Detail Information |
|||
| Model NO.: | Snowfall Truck Body | Size: | Customizable |
|---|---|---|---|
| Strength: | High Strength | Assembly: | Unique & Easy Installation |
| Production Method: | Formed At High Pressure By Vacuum Tech | Sealing: | Better Sealing |
| Installation: | Easy And Unique | Technology: | Internation Patented Technology |
| Production Capacity: | 150 Sets Per Month | Material: | New Type FRP |
| Heat Conductivity: | 0.20W/M².K (FRP), 0.018-0.028W/M².K (polyurethane Foam) | Overall Heat Transfer: | Below 0.3W/M².K |
| Fire Retardant: | B1 Level | Service Life: | 4-6 Times Longer Than Traditional |
| Weight Reduction: | 30-40% Lighter Than Traditional | ||
| Highlight: | refrigerated truck box with FRP panels,high strength refrigerated truck box,SNOWFALL refrigerated truck box |
||
Product Description
China Refrigerated Truck
Product Specifications
| Attribute | Value |
|---|---|
| Model NO. | snowfall truck body |
| Size | Customizable |
| Strength | High Strength |
| Assembly | Unique & Easy Installation |
| Production | Formed at High Pressure by Vacuum Tech |
| Durability | Stability & Consistency |
| Sealing | Better Sealing |
| Technology | Internation Patented Technology |
| Transport Package | Export Standard |
| Trademark | SNOWFALL |
| Origin | Guangzhou, China |
| HS Code | 8707909000 |
| Production Capacity | 150 Sets Per Month |
Product Description
High-performance refrigerated van body designed for optimal thermal insulation and durability.
Material & Performance
- New type FRP (Fiber Reinforced Plastic) used as inner skin
- Panel fixed to van inner skin for enhanced durability
Construction
- Full close structure design for maximum reliability
- Panels adhered with high strength structural adhesive for superior sealing and insulation
- Easy and fast assembly process
Specification
- High accuracy door panel process with imported sealing rubber for excellent airtight and thermal insulation
- Interior decorated with special aluminum alloy profiles or stainless steel components
- Protection guardrails installed on both sides and end of van
- Reinforced floor design with high quality figured aluminum floor panel for superior loading capacity
- Customizable design to meet specific material and structural requirements
- Optional interior compartments for different temperature zones
Key Properties
- Lightweight: 30-40% lighter than traditional products
- Thermal Insulation: Overall heat transfer coefficient below 0.3W/M².K
- Surface Durability: High tensile strength, chemical resistance, and UV protection
- Impermeability: Excellent water resistance on both sides
- Fire Retardant: Conforms to national standard B1 level
- Long Service Life: 4-6 times longer than traditional products
- Easy Maintenance: Repairs leave no visible traces
- Eco-Friendly: No volatile or corrosive substances, fluorine-free
- Refrigeration Options: Available with USA, German, or Chinese refrigerator groups
Our high-quality refrigerated trucks have been exported worldwide and enjoy excellent market reputation for their reliability and performance.
